Vacuum unit ISAB.10.100, 170 l/min, 380 V

SKU: 2478001
€531,00 with VAT
Only 5 left
Almost sold out
Pickup at the parcel locker

* Weight ≤30 kg · 39×38×64 cm.

Any questions?

Contact us

Customer Support

Chat Email
Category
Milking Equipment, Vacuum Units, Vacuum Units & Pumps

The vacuum device ADS.20.03.000 is designed to create and maintain vacuum pressure during machine washing.

Construction and operating principle:

With the help of the engine, the pump rotor rotates in the bearings (the direction of rotation is indicated by an arrow on the pump housing), creating vacuum pressure in the vacuum tank. By adjusting the vacuum regulator socket, set the vacuum pressure in the vacuum line to 50 ±1 kPa.

Technical specifications:

  • Vacuum system capacity: 170 l/min;
  • Electric motor power: 0.75 kW, 380V;
  • Nominal vacuum pump capacity at 48 kPa vacuum: 10.2 m³/h;
  • Dry vacuum pump – oil-free;
  • Dimensions: 50 x 30 x 60 cm;
  • Weight: 34 kg.
  • Vendor Larta 1
  • SKU 2478001
